Introduction; Proper Use; Description Of Parts And Features - Powerfix Profi Z31780 Montage-, Bedienungs- Und Sicherheitshinweise

the following icons / symbols are used in this instruction manual:
Read instruction manual!
Observe caution and safety notes!
Caution – electric shock!
Danger to life!
Risk of fire!
Dispose packaging and appliance in
an environmentally-friendly way!
Angle grInDer StAnD

Introduction

We congratulate you on the purchase
of your new product. You have chosen
a high quality product. Familiarise
yourself with the product before using it for the first
time. In addition, please carefully refer to the oper-
ating instructions and the safety advice below.
Only use the product as instructed and only for the
indicated field of application. Keep these instruc-
tions in a safe place. If you pass the product on to
anyone else, please ensure that you also pass on
all the documentation with it.

Proper use

This product is intended to provide a method of
holding a hand-held angle grinder in a fixed position
while using it for cutting. The product is suitable for
most hand-held angle grinders that take a disc 115
or 125 mm diameter disc. Any use other than that
described above or modification to the product is
not permitted and could lead to injury and/or dam-
age to the product. The manufacturer accepts no li-
ability for loss or damage arising from improper use.
6 GB
Never leave children unsupervised
with the packaging materials or the
device.
Wear protective glasses, hearing
protection, protective gloves and dust
protection mask.
Do not allow anyone else to come
within the working range of the device
while you are using it.
Avoid any backwards movement
and apply even pressure on the
workpiece.
The product is not intended for commercial use.
Description of parts
and features
Adjustment screw with rubber buffer (short)
1
Metal rod
2
Handle
3
Nut (guard mount)
4
Safety guard
5
Plastic bushing M6
6
Plastic bushing M8
7
Washer (mounting bolt)
8
Mounting bolt M6 (angle grinder)
9
Mounting bolt M8 (angle grinder)
10
Mounting bolt M10 (angle grinder)
11
Nut (mounting bolt M6 angle grinder)
12
Nut (mounting bolt M8 angle grinder)
13
Nut (mounting bolt M10 angle grinder)
14
Distance piece (60 mm)
15
Distance piece (90 mm)
16
Distance piece (130 mm)
17
Front mounting piece
18
Plastic locating piece (mounting piece)
19
Adjustment screw with rubber buffer (long)
20
Fastening screw (vice)
21
Rotary adjustment knob (vice)
22
