Extremis WALRUS Bedienungsanleitung Seite 7

3
2
5. Now attach the arm rest to the frame, using 3 M8x20 bolts and M8 flat washer on each bolt.
PLEASE NOTE
: make sure the holes match up, and then tighten all the bolts in the arm and back rest.
TIP
: tighten the bolt at the front first
6. Now attach the tabletop to the frame, using 4 M8x12
bolts and an M8 flat washer on each bolt.
PLEASE NOTE
: make sure the holes match up, and
then tighten all the bolts in the tabletop and backrest.
8. Fix it in place by attaching the Velcro straps to the two
rods in the middle.
1
1
, then the one at the back
2
and lastly the one in the middle
7. Place the seat cushion on the frame
OPTIONAL
1. Open the cover of the back rest. Attach the blanket to
the backrest using the glass fibre rod (L = 985 mm)
included with the blanket.
2. Drape the blanket over the sofa and add the cushion.
3
.
english 7
