Wall installation

Feed the guide tabs (1) on the wall-mounting bracket (2) in the slots (3) on
the rear side of the telephone. Slide the wall-mounting bracket 10 mm up­
wards until it audibly locks into place. Drill a hole and insert a screw leav­
ing about 5 mm of the screw projecting from the wall. Guide the mounting
hole (4) in the mounting bracket (2) over the screw and slide the telephone
downwards.
Attention: Ensure there are no cables in the wall at the point
where the hole is drilled.
Turn the hook in the receiver cradle so that the receiver can be placed on-
hook.
5
3
3
2
4
1
5
5
5
5
Preparing the Telephone
