Putting the Telephone into Operation

Wall installation

Feed the guide tabs (1) on the wall−mounting bracket (2) in the slots (3) on
the underside of the telephone. Slide the wall−mounting bracket 10 mm
upwards until it audibly locks into place. Drill a hole and insert a screw
leaving about 5 mm of the screw projecting from the wall. Guide the
mounting hole (4) in the mounting bracket (2) over the screw and slide the
telephone downwards.
Caution: Ensure there are no electrical cables, water pipes etc.
in the wall where the hole is drilled.
Turn the hook (5) in the receiver cradle so that the receiver can be placed
on−hook.
5
26
3
3
2
4
1
5
5
5 5
