When the air temperature drops below the set temperature, the
unit will come back on. If the heater is not operating this may be
because the set temperature is lower than the room temperature. If
no buttons have been pressed for 10 seconds, the display screen
will go into sleep mode. The screen backlight will fade to 20% of
its intensity.
Note: When in heating mode if the " " button is pressed the fan
will continue to run for 15 seconds while counting down 10 to 1
on screen.
Audio - see Fig. 6
When a button is pressed the heater emits and audible beep. If the "
" + " " buttons are pressed and held for 2 seconds this will turn off
audio for button presses. If both buttons are pressed and held again
the audio will be turned on again. The screen will show either the audio
on or audio off symbols as shown in Fig. 6. After 2 seconds display
will return to the temperature screen.
Fan Only Mode - Fig. 7
If the " " + " " buttons are pressed and held for 2 seconds this will
switch the appliance into fan only mode. In this mode the heating
elements are powered down and the appliance will blow cool air.
The fan symbol " " will appear on the display when the appliance
is in fan only mode. If the " " + " " buttons are pressed and held
again for 2 seconds this will switch the appliance out of fan only
mode and the display screen will return to the temperature screen.
Oscillation - See Fig. 8 & Fig. 12 (M2GTS/B Only)
The heater can be switched into oscillation mode by pressing the
" " button on the control panel. An oscillation graphic will appear at
the top of the temperature screen, see Fig. 8. The heater oscillates
back and forth on its base through 90 degrees as shown in Fig. 12.
Power Settings - see Fig. 10
The heater has 3 power settings. To cycle through these settings,
press and hold the " " button for 2 seconds. This will bring up the
power setting screen. Press the " " button again to cycle through
the 3 settings, "Low", "High" and "Eco", as shown in Fig. 10. The
settings will flash when displayed on the screen. Once a setting
is left highlighted for 6 seconds it will then become selected and
return to the temperature screen. Press the " " button at any
time to cancel the operation. When in "Eco" setting the heater will
automatically switch between "High" (2000W) and "Low" (1000W)
setting as required to maintain the set temperature.
'Intelligent' Eco Mode
This is the appliance default setting, the appliance will automatically
start up in this setting once power is applied and the standby key is
pressed. The LCD display will indicate the desired room temperature
and the appliance will automatically regulate the room temperature
accordingly. In this mode the appliance operates at full power,
however the output of the appliance is automatically reduced and
regulated as the room temperature approaches the desired level.
This mode optimises energy use by calculating the most efficient
and effective way to achieve the desired temperature setting. The
desired room temperature can be adjusted at any time during
operation by pressing the appropriate key.
Runback Timer Mode - See Fig. 11
The heater is fitted with a run-back timer feature which can be set
in any of the operating modes. Press the
runback timer screen. The runback timer range is 1 to 12 hours.
The displayed runback time will be flashing on screen, starting
at "01 Hrs". Press the " " button again to increase the runback
time by 1 hour. Pressing " " will cancel the runback operation.
Once the desired runback time is left to flash for 6 seconds the
timer will be set. The display will switch back to the temperature
screen with the runback countdown displayed below as shown in
Fig. 11. To cancel the current runback timer, press the " " button.
The runback countdown will flash to "OFF" then disappear.
the run time has been set the heater will run and the runback
countdown will remain on the display until the set time runs out.
At this point the heater will switch to standby mode. To turn the
heater back on, press the
Note: If runback countdown is active in Fan mode the text below the
fan symbol will alternate between "Fan" and runback countdown.
Tilt Switch
The heater is fitted with a tilt switch which will prevent the heater
from working if the heater is accidentally tipped over in any
direction. The switch mechanism makes a rattling noise when the
heater is moved or tilted, this is not a fault, this noise is normal.
" " button to switch to the
" " button.
Overheat Protection
The heater is fitted with a temperature limiter. If the air inlet or outlet
grilles are restricted in anyway the temperature limiter switches the
heater off automatically. To bring the heater back into operation,
remove the cause of overheating then unplug the unit from the
electricity supply for a few minutes. When the heater has cooled
sufficiently reconnect and switch on the heater.
Electronic Thermostat
In addition, if the electronic thermostat reads an abnormal ambient
room temperature it will cut the power to the heater and display
"ERROR" on screen. When the temperature has cooled to an
acceptable ambient room temperature it will restore power to the
heater and "ERROR" will disappear from the screen. The heater
will return to previous operation mode. The heater will then operate
as normal, if the heater does not switch on this may be because
the room temperature is still warmer than the set temperature.
Air Filter - see Fig 13.
This heater is provided with an air filter. Dust and fluff can
accumulate in the filter and to avoid overheating of the element
the filter should be cleaned when required. To clean the filter
remove the filter cover from the back of the heater (see (A) in Fig.
13). The filter (see (B) in Fig.13) can be taken from the filter cover
and dust or fluff can then be removed using a vacuum cleaner.
When cleaning of the filter is complete the filter should be refitted
to the filter cover. The filter cover should then be refitted to the
rear of the product.
Note: Disconnect the heater from the power supply before cleaning
the filter.
Cleaning
Switch off the appliance first and disconnect the plug from the
socket. Clean the housing with a moist cloth, vacuum cleaner or
brush. Do not use any abrasive or caustic cleaning agents. Do
not use any flammable cleaning agents e.g. petrol or spirit for
cleaning the appliance. Never immerse the appliance in water.
Air inlet and outlet area should be cleaned with a vacuum cleaner
regularly· If the appliance is not used for extended periods, it must
be protected against excessive dust and dirt.
Recycling
For electrical products sold within the European
Community. At the end of the electrical products useful
life it should not be disposed of with household waste.
Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice in your
country.
After Sales Service
Your product is guaranteed for two years from the date of
purchase. Should you require after sales service, please contact
the retailer from whom the appliance was purchased or contact
the service number relevant to your country on the warranty card.
Please do not return a faulty product to us in the first instance
as this may result in loss or damage and delay in providing you
with a satisfactory service. Please retain your receipt as proof of
purchase.
Model Identifier(s):
Heat output
Nominal heat output
Minimum heat output (indicative)
Maximum continuous heat output
Once
Auxiliary electricity Consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat output/ room temperature control
Electronic room temperature control
Contact details
M2GT/B M2GTS/B
Pnom 2.0 2.0
Pmin 1.0 1.0
Pmax,c 2.0 2.0
elmax 0.0 0.0
elmin 0.0 0.0
elSB 0.00046 0.00046
GDHVI
Dunleer, Co. Louth, Ireland
kW
kW
kW
kW
kW
kW
Yes
