Entry 6 MAX code P07EN10018
Pos. Code
1 S40FN55021 Entry LH side panel 6-9 MAX
2 S40FN55023 Entry RH side panel 6-9 MAX
3 S35FN55066 Entry complete door 4-6-8-12 MAX
3.1 S66PT55025 Entry door assembly 4-6-8-12 MAX
3.2 S34FN55016 Counterdoor assembly 4-6-8-12 MAX
3.3 A90MI65003 Elesa handle I 280/115 M12
3.4 A00PT55003 Entry glass ceramic plate
3.5 A94GU65002 Joint Entry
4 A95OO65009 Hollow tile 350x1050x14
5 A87RZ65065 Resistor 3650 W 230 V
6 A87RZ65065 Resistor 3650 W 230 V
7 A90MP65001 Spheric knob PLX.30-M8-C9
8 A87IL74003
9 A87CX62006
10 A87IL73006
11 A87IL72010
12 A86EL46004
13 A86EL47003
14 A88TX77007 Single-phase thermostat Tmax=400°
15 A87AZ69006
16 S73FN55009
17 A87IL72005
18 A88TC83001
19 A93OL65049 Entry control label MAX PizzaGroup
20 A87AZ69004 Four-pole switch 16A
22 A93AD00011 Resin coated label "PizzaGroup"
27 A86EL48001 Equipotential connection
Description
Round lamp glass
Mammut assembly
Lamp holder Vossloh Schwabe E14 Type
Incandescent lamp 40W 230V E14
Cable gland OBO 106 PG 21
Nut for cable gland OBO 106 PG 11
Red single-pole switch
Thermostat knob AP10 scale 0-10
Warning light lamp 380 V
Analogue thermometer 0-500°C
