PizzaGroup ENTRY MAX 4 Gebrauchsanweisungen Seite 72

Entry 8 MAX code P07EN10021
Pos. Code
1 S40FN55003 Entry LH side panel 8-12L MAX
2 S40FN55001 Entry RH side panel 8-12L MAX
3 S35FN55066 Entry complete door 4-6-8-12 MAX
3.1 S66PT55025
3.2 S34FN55016 Counterdoor assembly 4-6-8-12 MAX
3.3 A90MI65003
3.4 A00PT55003
3.5 A94GU65002 Joint Entry
4 A95OO65008 Hollow tile 350x700x14
5 A87RZ65005 Resistor 2800 W 230 V Prime 4-8
6 A87RZ65005 Resistor 2800 W 230 V Prime 4-8
7 A90MP65001 Spheric knob PLX.30-M8-C9
8 A87IL74003
9 A87CX62006 Mammut assembly
10 A87IL73006
11 A87IL72010
12 A86EL46004
13 A86EL47003
14 A88TX77007
15 A87AZ69006
16 S73FN55009 Thermostat knob AP10 scale 0-10
17 A87IL72005
18 A88TC83001 Analogue thermometer 0-500°C
19 A93OL65049 Entry control label MAX PizzaGroup
20 A87AZ69004
22
A93AD00011 Resin coated label "PizzaGroup"
27
A86EL48001
Description
Entry door assembly 4-6-8-12 MAX
Elesa handle I 280/115 M12
Entry glass ceramic plate
Round lamp glass
Lamp holder Vossloh Schwabe E14 Type
Incandescent lamp 40W 230V E14
Cable gland OBO 106 PG 21
Nut for cable gland OBO 106 PG 11
Single-phase thermostat Tmax=400°
Red single-pole switch
Warning light lamp 380 V
Four-pole switch 16A
Equipotential connection
- 72 -
