4
Q U I C K G U I D E
Uponor Smatrix
Move
Uponor Smatrix Move
components
An Uponor Smatrix Move system may be a combination
of the following components:
Uponor Smatrix Move X-157 (controller)
Uponor Smatrix S-1XX (outdoor sensor)
Uponor Smatrix Move S-152
(supply/return sensor)
Uponor Smatrix Move A-155
(antenna A-155)
Requires antenna A-155:
Uponor Smatrix Wave T-169
(digital thermostat with RH T-169)
Uponor Smatrix Wave T-168
(programmable thermostat with RH T-168)
Uponor Smatrix Wave T-166
(digital thermostat T-166)
Uponor Smatrix Wave T-163
(public thermostat T-163)

System example (wired)

N O T E !
If the outdoor sensor is placed to far
away from the reference room, a separate
thermostat can be used to register the
outdoor sensor.
U P O N O R S M AT R I X M O V E · Q U I C K G U I D E
