N O T E !
Some system parameter settings are only
accessible during the fi rst 4 hours after
power up. This is done to prevent mistakes
after installation. If the locked system
parameter symbol is displayed, the power
to the controller has to be disconnected
and reconnected again to modify these
parameters. No settings are lost when
disconnecting or after a power failure.
The settings available while in run mode is
always accessible for change, and will not be
locked.
To enter system parameter settings:
1. Press and hold the OK button for about 10 seconds.
2. The settings icon is displayed in the top left hand
corner of the display, and the text Hot type, Cld
type, or rEv type (depending of current operating
mode) is displayed.
3. Use buttons < or > to locate a parameter (see list
below) and press OK.
Some of these parameters require other parameters
to activate them.
Menu Display Description
0 type Type of installation (heating and/
or cooling)
Cur
1 Heating curve
See page 12 for more information
and a diagram
2 Hi Maximum supply temperature
(heating mode)
3 Lo Minimum supply temperature
(heating mode)
1 Cur Cooling curve
See page 12 for more information
and a diagram
2 Hi Maximum supply temperature
(cooling mode)
Lo
3 Minimum supply temperature
(cooling mode)
4 InSt Type of system (hydraulic
installation)
5* th Thermostat selection (installed/
wireless/etc, see the registration
instruction on pages 8 – 10)
U P O N O R S M AT R I X M O V E · Q U I C K G U I D E
Q U I C K G U I D E
*) Requires antenna A-155
**) Requires a return sensor
4. Use buttons - or + to change parameter settings.
5. Use buttons < or > to locate parameter 24 (End)
– Exit system parameter settings.
6. Press the OK button to exit the system parameter
settings.
Menu Display Description
tHty
6 Not used by Move
7** BGAP Boost function if the difference
between the supply and return
temperature is too much
trF1
8* Wireless thermostat 1 confi guration
(see the registration instruction on
pages 8 – 10)
9* trF2 Wireless thermostat 2 confi guration
(see the registration instruction on
pages 8 – 10)
This thermostat controls the
operation of circulation pump 2
10* tr1o Supply temperature compensation
when using a thermostat to speed
up the system. Use with caution
11 in1 Wired input 1, select function
12 in2 Wired input 2, select function
13 OUSE Outdoor sensor selection
(installed/wireless*/wired/etc,
see the registration instruction on
pages 8 – 10)
14 OUt Outdoor temperature, fi xed value if
outdoor sensor is not installed
ourF
15* Wireless outdoor sensor
confi guration (see the registration
instruction on pages 8 – 10)
16 ˚C Display unit
17 00:00 Time unit (AM/PM/24H)
18 GriP Valve and pump exercise
PUMP
19 Pump start delay after the mixer
valve is closed
20 ctrl Forced control of the actuator
PrH
21 Floor/screed preheating program
DIN 1264-4
22 dry Floor/screed drying program
23 ALL Factory reset
Press and hold the OK button for
about 5 seconds
24 End Exit system parameter settings
