Assembly
➜ Open hood and plug the deflector plate
into the 4 cutouts of lower part.
✓ The deflector plate grants proper
distribution of hot air under the hood.
✓ When closed, the integrated magnets
keep hood in position.
The incubator has friction hinges. This allows the user to open it to
any position. System related, a moderate force is required to open
and close the hood.
For cleaning, hood can be dismounted. To do so undo knurled screws
and lift off hood.
Deflector plate
Cutouts
