Maintenance
7. Place the support disc in the hood, ensure that the visor is
flush to and congruent with the support disc.
8. Pull the washbag over the hood and ensure that the
washbag foam rests on the visor and the corded edge of
the washbag covers the lower edge of the visor. Tighten
and tie the cord.
9. Turn up the socks or protective boots once. Avoid sharp
bends.
10. Place the sleeves into the centre of the chest section.
Smooth out any creases.
11. Fold the hood with the washbag and the upper section of
the chemical protective suit to ensure that the visor lies on
the rolled-up safety boots. Smooth out any creases. Make
sure that the visor does not get deformed.
12. Place the chemical protective suit into the industrial
washing machine.
13. Start the washing program "Chemical protective suit".
CAUTION
!
Risk of damaging the material!
To avoid damaging the chemical protective suit, the
wash drum must only move when filled with water.
Observe the following parameters during washing:
Water temperature for cleaning and disinfecting:

62 °C ±2 °C
4 rinse cycles with clear, cold water

14. Dry all parts (see Chap. 6.3.3 on Page 28).
6.3.3 Drying the chemical protective suit
CAUTION
!
Risk of damaging the material!
To avoid the chemical protective suit being damaged,
it must not be spin-dried.
To avoid mould formation, for example, the chemical
protective suit must be completely dry.
1. Before drying, tip out any remaining liquid from the
chemical protective suit or wipe with a sponge.
2. Dry all parts thoroughly inside and outside.
The chemical protective suit can be blow-dried using dry,
oil-free compressed air or in a protective suit dryer system:
– Temperature: maximum 40 °C
– Time: min. 120 minutes
Avoid direct heat radiation or direct sunlight.
NOTICE
i i
Suitable drying systems for the chemical protective
suit include:
TopTrock SF01 with GF fan

Drying systems of an equivalent design

3. Reinsert the backpack pad.
4. Carry out a visual inspection of chemical protective suit,
visor, safety boots and gloves.
5. Reinsert the antifog visor (if fitted).
6. Refit the ventilation unit and D-connect (if fitted).
28
6.4

Maintaining the fastener system

1. Lubricate the fastener system thoroughly after every use
and every cleaning and disinfection process. Use the
grease stick available from Dräger to do this.
2. In particular, lubricate the chain links on the zip fastener
and the area below the chain links on which the zip is
running.
NOTICE
i i
To prevent the closure system sticking, protruding
textile threads must be removed.
6.5 Examining tightness of the chemical
protective suit
The test is described for the test device Porta Control 3000.
You can carry out the tests with other test devices, but the
indicated values must be observed.
Carry out the test according to ISO 17491-1, method A.2 at
constant room temperature (20 °C±5 °C).
The compressed air used must comply with the requirements
of EN 12021.
The required test accessories are listed in the order list (see
Chapter 11 on Page 36).
6.5.1 Preparation of test
1. Seal the connections for protective suits with ventilation
unit.
2. Close the fastener system.
3. Spread out the chemical protective suit front-down on a
clean and even surface.
4. Protect the visor with a soft underlay in order to avoid
scratches.
5. Unfasten the protective cap from both suit valves and
remove the valve discs.
6. Fit one test cap on one suit valve and connect it to the test
unit via the blue test hose.
7. Fit another test cap on the other suit valve.
8. Ensure that both valves are connected to the black hose of
the test unit.
9. Connect the test cap to the compressed air supply (6 bar)
via the black hose.
Carry out the test (see Chap. 6.5.2 on Page 28).

6.5.2

Carrying out the test

CAUTION
!
If the suit is overfilled, the material will be damaged.
When filling the chemical protective suit ensure that
the pressure does not exceed the specified values.
1. Open the blow up valve on the black hose and fill the
chemical protective suit until the test unit shows 17.5 mbar.
Close the blow up valve.
2. Set a settling time of 10 minutes start the stopwatch.
During this time, keep the pressure at approx. 17 mbar so
that a pressure and temperature compensation can be
carried out. If required, top up the air.
3. Open the relief valve. Lower the pressure to 16.5 mbar.
Close the relief valve.
4. Set a test time of 6 minutes and start the stopwatch.
Dräger CPS 6900
