Specifications - Interlogix AD600 Installationsanleitung

AD1000 requires a 3 core connection to the ATS1290N DGP /
ATS Master panel. See Figure 3.
•
DIP switches 1–5: Adress setting 0–31
• DIP switch 6: Adress setting –61 (BUS-1 only, ATS IADS
bus OFF)
•
DIP switch 7: OFF-ATS IADS bus, ON-universal BUS-1*
•
DIP switch 8: OFF (not used)
•
Sp / Spare: Potential free terminal
• − / GND: Connect to "−" AUX power of ATS Master panel
• D / Bus: Connect to "+" IADS bus output of ATS1290N
• + / +12V: Connect to "+" AUX power ATS Master panel
* For further details on Universal BUS-1 visit the download
area www.support-security.de.
Examples for IADS address setting
•
Address 00 = DIP 0000 0000
•
Address 08 = DIP 0001 0000
•
Address 15 = DIP 1111 0000
•
Address 31 = DIP 1111 1000
Note: DIP switch 8 must stay in OFF position.
Learn-in procedure und programming
After powering up the AD600/AD1000 units installed in the
conventional detectors, wait 2 minutes for the correct
initialization before starting the learn mode.
AD600 and AD1000 are compatible with all known IADS-
devices as AD011, AD111, AD044, EV435-AD, EV435AM-AD,
DD205-AD, MK46-AD, and can be used in any combination
with existing installed devices accordantly to the selected DGP
mode (16 or 32 devices).
As conventional detectors are powered via the panel power
supply and not via the IADS bus, up to 32X AD600/AD1000
devices can be used with the ATS1290N DGP.
After the learn-in procedure, AD600 / AD1000 will be identified
as "EV435-AD" and allow you to program the corresponding
zone number depending of the IADS-address and outputs for
the walk test and alarm memory function. As only conventional
detectors are connected to AD600/AD1000, the range setting
(location 3) and process mode (location 4) cannot be used. By
default outputs of AD600 / AD1000 are for positive (+12 V)
control voltage for controlling the walk test LED and the
day/night function of the DD600/EV1000/VE1000 detectors. In
case the polarity needs to be changes, this can be done by
inverting the corresponding ATS-outputs for the walk test and
day/night inputs of the detector.
Limitations when connecting AM-detectors to AD600 /
AD1000
As the AD600/AD1000 are acting as I/O interfaces with one
dual-zone input and two outputs, it is necessary to program
anti-masking detectors to signal a technical fault or
antimasking condition to the alarm output.

Specifications

Supply voltage 9 to 24 V
IADS-bus voltage 12 or 24 V
400 µA — alarm and tamper inputs open,
Min. current
consumption at 13,4 V walk test and day/night outputs
programmed for "+"
P/N 466-2677 (ML) • REV D • ISS 08JUN16
(12 V nominal)
900 µA — alarm and tamper inputs closed,
Max. current
consumption at 13,4 V walk test and day/night outputs
programmed for "−" (approx. 100 µA per
input and 135 µA per output)
approx. 75 µA
Bus current consumption
out of bus
Unit load for DGP 1
200 mA (using "−")
Max. current capacity
output day/night
200 mA (using "−")
Max. current capacity
output walk test
Device type / category T3 / PIR
Address range 0 to 31
Regulatory information
Manufacturer PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
European Union UTC Fire & Security hereby declares that this
directives device is in compliance with the applicable
requirements and provisions of one or more of the
Directives 1999/5/EC, 2014/30/EU and 2014/35/EU.
For more information see
www.utcfireandsecurity.com or www.interlogix.com.
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For
more information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
DE: Montageanleitung
Beschreibung
Die Busmodule AD600 und AD1000 IADS werden von der
ATS1290N AME unterstützt und lassen sich direkt an den
Anschlussklemmleisten der folgenden Melder installieren:
•
AD600: DD666-D / DD666AM-D
•
AD1000: EV1000-Serie / VE1000-Serie / DD1000-Serie
Abbildung 1: AD600 / AD1000 – Aufbau
Abbildung 2: AD600 – Anschlüsse
Abbildung 3: AD1000 – Anschlüsse
Abbildung 4: AD600 nach Montage in Meldersockel DD666
Abbildung 5: AD1000 nach Montage in Meldersockel EV1116
