6.6 - SAFETY DEVICES

"Partial stop" (N.C.) socket
- input for safety devices such as photocells, sensitive
edges and other EN 12978-compliant devices. Halts
moving gate leaves and causes them to automatically
close
"Open during closing" (N.C.) socket
- Input for safety devices such as photocells, sensitive
edges and other EN 12978 compliant devices. When gate
leaves are closing, opening the contact causes reversal
until total opening is obtained.
"Partial Stop" (N.C.) socket
"Open during closing" (N.C.) socket
DIR photocells
RX
DIR photocells
RX
DOC photocells
RX
DOC photocells
RX
TX
TX
TX
TX
