01 - Photosensor
02 - Lens
03 - Infrared LEDs
04 - PIR Detector
05 - Loudspeaker
06 - Microphone
07 - Power Connector
08 - Status LED
09 - WPS / Reset
10 - Antenna Connector
11 - Network Port
12 - Audio Output
13 - MicroSD Card Slot
14 - Mount
15 - Camera Label
4.3. Status LEDs
Status LED
Constant on
Slow Flashing
Fast Flashing
Off
Go to http://install.instar.com
Twilight switch for IR LEDs
Wide-angle (focal length: 4.3mm / field of view: ~ 90º dia.)
12 IR LEDs (nightvision @ 850nm)
Integrated passive infrared motion detector
Integrated loudspeaker
For noise detection / audio rec. / two-way audio intercom
5V / 1.5A DC - Plug Ø : 1.35mm (in) / 3.5mm (out)
blue: network status (can be turned on/off)
Please refer to below Chapter 4.3 Status LED
3 seconds for quick WiFi setup / 15-20 seconds for reset
SMA connector (incl. 2,4dB antenna / not for PoE version)
RJ45 LAN-port / connector for Cat5e LAN cable or higher
3.5mm jack for earphone / active speaker
Slot for MicroSD/SDHC cards (max. 32GB - 8GB included)
Standard camera thread for included bracket (1/4"-20 UNC)
P2P ID, LAN MAC address and serial number
Blue LED
Booting process
LAN connection
WiFi connection
Firmware update
in process or
LED is turned off
Green LED
-
-
Data transfer
through LAN
No network cable
connected or in
WiFi mode
Orange LED
Network cable is con-
nected or in WiFi mode
-
-
Network cable is not
connected correctly
