Induction Heater F – 2300
ENG
Introduction
The Induction Heater F – 2300 is a power tool to heat magnetisable metal, such as a screw
or any other object. It's best to try yourself what other materials can be heated. There are
eight different induction coils and two induction tubes separately available for the heating of
various objects.
Before using the F - 2300, read the operating instructions carefully!

Scope of delivery

The F - 2300 comes as a complete set in a case with the following contents:
Induction heater F - 2300
■
Induction coils in Ø 18; 23; 26
■
Hose 1.1 m long
■
Power cable with IEC lock
■
Operating instructions
■
Product data
Technical data
Voltage:
■
Frequency:
■
Power:
■
Protection class: IP20
■
Insulation class: I
■
The use of a power generator is allowed, provided it offers sufficient power and the initial
■
voltage is a pure sine-wave voltage in the right frequency range (50 – 60 Hz).
Safety Notes
Always connect the device to a power circuit with a fuse of at least 10 A and a maximum of
16 A (the device does not have an internal fuse itself).
To be on the safe side always use a wall socket with protective conductor (class I). The
device does not have a power switch for ON and OFF. When the power cord is plugged in the
device is on.
Environmental conditions
Temperature range: -5 °C up to +40 °C
■
Humidity: 0 – 90 %, no condensing
■
Do not use in an area more than 2,000 metres above sea level
■
Operation
Pictograms
The pictograms on the Induction Heater F – 2300 have the following meaning:
Attention! Magnetic field created.
As a result magnetic data on bank cards etc. could be deleted.
230 VAC +/-10 %
50 – 60 Hz
2.300 W
