Connection to the sounder sensor is via a 30 cm coaxial cable and an overmoulded RCA
connector.
3.2.3. Connections
Connect the sounder sensor to the RCA connector
Connect the speedometer sensor to the LT8 connector
Connect the - power to the black wire without connector and the red wire to the +
power via a switch and a 1A fuse.
For a system comprising several "Advansea" instruments, connect all the orange
bus wires from each instrument together.
Connect an NMEA source (GPS for example) to the yellow wire for the +nmea and
the black for the – nmea
See diagram below:
