Connection and starting
The following table shall give a rough orientation for the adjustment of subwoofer crossover
frequency.
Loudspeaker set up
Surround system with LFE-Channel
Audio system with miniature speakers
ELAC 301, Starlet;
all Cinema 2, 1, 07, 05 components
HiFi-system with small bookshelf speakers
HiFi-system with full range speakers
10 LED for Bluetooth® activity
once every 7 seconds (= BT stand-by). If a Bluetooth® source is connecting to the receiver
the LED will light permanently until the audio transmission begins (= BT waiting).
During normal Bluetooth® audio transmission the LED will flash up with a 1 second cycle.
Again the twinkle sequences are shown graphically as follows.
permanent
1 seconds
7 seconds
permanent
8 seconds
Note:
The following chapter explains the Bluetooth® wireless technology in more detail.
Please read carefully because some special features of this transmission standard and its
protocol (A2DP) are mentioned.
This signals the working status of the Bluetooth® receiver. After selection
of POWER mode to "ON" (see pt. 6) the LED will twinkle for 1 second,
indicating the start up of the receiver module. If there is no Bluetooth®
source actively connected to the receiver the LED will flash up shortly
Bluetooth® not activated
Start of the Bluetooth® receiver module
Bluetooth® active, but no connection
Bluetooth® active and connected, no audio transmission
Bluetooth® active, connected, audio transmission working
Crossover adj. at ELAC subwoofer
180 Hz
180 Hz
120 Hz
120 Hz
60 Hz
30
