Manuale tecnico posto esterno Ikall Art. 4680C, Art. 4680KC
Technical manual for Ikall external unit Art. 4680C, Art. 4680KC
Manuel technique poste extérieur Ikall Art. 4680C, Art. 4680KC
Technische handleiding entreepaneel Ikall Art. 4680C, Art. 4680KC
Technische Anleitung Außensprechstelle Ikall Art. 4680C, Art. 4680KC
Manual técnico de la unidad externa Ikall Art. 4680C, Art. 4680KC
Manual técnico posto externo Ikall Art. 4680C, Art. 4680KC
Verwandte Anleitungen für Comelit 4680C
Inhaltszusammenfassung für Comelit 4680C
- Seite 1 Manuel technique poste extérieur Ikall Art. 4680C, Art. 4680KC Technische handleiding entreepaneel Ikall Art. 4680C, Art. 4680KC Technische Anleitung Außensprechstelle Ikall Art. 4680C, Art. 4680KC Manual técnico de la unidad externa Ikall Art. 4680C, Art. 4680KC Manual técnico posto externo Ikall Art. 4680C, Art. 4680KC...
- Seite 2 • Install the equipment by carefully following the instructions given by the manufacturer and in compliance with the standards in force. • All the equipment must only be used for the purpose it was designed for. Comelit Group S.p.A. declines any responsibility for improper use of the apparatus, for modifications made by third parties for any reason or purpose, and for the use of non-original accessories and materials.
- Seite 3 Installazione posto esterno Installation der Außensprechstelle Installing the external unit Instalación de la unidad externa Installation poste extérieur Instalação do posto externo Installatie entreepaneel Selezione illuminazione led cartellini Lasciare in posizione la protezione di impianto. portanome. Leave the system protection device Nameplate LED lighting selection.
-
Seite 4: Installations
Gespräch mit einer anderen Außensprechstelle geführt. levels, please refer to technical manuals MT/SBC/01, FT/SBC/04. • Modules Art. 4680C, Art. 4680KC normally function as the main external unit (timed busy signal). • Bei einem anhaltenden Kurzschluss auf der Busleitung gibt die Außensprechstelle To set them as a secondary external unit (busy signal active for the whole time the riser is in use), einen intermittierenden Hinweiston aus. - Seite 5 4680K 4680K CONFIGURAZIONE RAPIDA FUNZIONE: "Attivazione relè C.NC.NO su comando attuatore: 2 sec" Valido per Art. 4680C con IR 041 o superiore 4680C e Art. 4680KC con IR 007 o superiore Settare i dip in modo permanente come da figura (Dip switch ON 8, Dip switch OFF 1,2,3,4,5,6,7)
- Seite 6 Call transmission: triple Envoi appel : triple Gestione posti interni collegati all'Art. 4680C: Control of internal units connected to Art. Gestion postes intérieurs reliés à l'Art. 4680C : 1,5,6,7,8 fino a 70 (default) 4680C: up to 70 (default) jusqu'à 70 (par défaut) Gestione posti interni collegati all'Art.
- Seite 7 2,4,5,6,7,8 Oproep verzenden: drievoudig Anruf: dreifach Envío de llamada: triple Beheer binnentoestellen aangesloten op art. Verwaltung von Innensprechstellen an Art. 4680C: Gestión de unidades internas conectadas al art. 1,5,6,7,8 4680C: tot 70 (standaard) bis 70 (Voreinstellung) 4680C: hasta 70 (predefinido) Beheer binnentoestellen aangesloten op art.
- Seite 8 Envio chamada: tripla Gestão dos postos internos ligados ao art. 1,5,6,7,8 4680C: até 70 (predefinição) Gestão dos postos internos ligados ao art. 2,5,6,7,8 4680C: de 71 a 100 Modo instalação Simplebus (predefinição) 1,2,3,4,5,6,7,8 Simplebus Top (NO art. 4680KC) 2,3,4,5,6,7,8 Reposição predefinição...
- Seite 9 Programmazione scambio Art. 1224A Programmierung der Signalweiche Art. 1224A Programming switching device Art. 1224A Programación del conmutador art. 1224A Programmation du commutateur Art. 1224A Programação do comutador art. 1224A Programmering selector art. 1224A laagste en hoogste code die op deze stamleiding kan worden •...
-
Seite 10: Dip Switch Programming Table
Tabella di programmazione dei dip switch Dipschalter-Programmiertabelle Dip switch programming table Tabla de programación de los DIP switches Tableau de programmation des DIP switches Tabela de programação dos dip switches Programmeringstabel van de dipswitches Codice / Codice / Codice / Codice / Dip switch ON Nome / Name... - Seite 11 B MAX C MAX D MAX E MAX F MAX G MAX H MAX Art. 1216 Comelit Art. 4577 1 mm (Ø 1,2 mm AWG 17) 200 m 200 m 200 m 200 m 150 m 50 m 50 m...
- Seite 12 26 - 28 Vdc 1595 120-230V * 20 M max *Pulsante comando apriporta locale *Local door-opener button 26 - 28 Vdc *Bouton commande ouvre-porte local *Bedieningsknop lokale deuropener *Lokale Türö nertaste *Pulsador abrepuertas local 4680C/ *Botão de comando abertura da porta local 4680KC...
- Seite 13 *Lokale Türö nertaste *Pulsador abrepuertas local *Botão de comando abertura da porta local 4680K/ 4680/ 4680KC/ 4680C SB2/SNP Variante con serratura di sicurezza e alimentazione aggiuntiva Variante mit Sicherheits-Türöffner und zusätzlicher Stromversorgung Variant with security door lock and additional power supply Variante con cerradura de seguridad y alimentación adicional...
- Seite 14 6. Para utilizar no comando actuador, consultar a tabela de programações especiais na pág. 6. 4680K/ 4680/ 4680KC/ 4680C SBV/DO Variante utilizzo segnalazione porta aperta. Einsatzvariante der Meldung tür o en. Da utilizzare solo in impianti con 1 solo posto esterno senza Verwendung nur in Anlagen mit 1 Außensprechstelle ohne...
- Seite 15 Variante connexion protections pour ligne Art. 1237 Variante para a ligação das protecções para a linha art. 1237 Aansluitvariant lijnbeveiligingen art. 1237 4680C/ 4680KC Utilizzo della rete RC per filtro serratura sui contatti del relè Verwendung des RC-Glieds als Türöffner-Filter an den Relaiskontakten Using the RC network for door lock filter on relay contacts Uso de la red RC para el filtro de la cerradura en los contactos del relé...
