VARIABLES
F3 Fan status with compressor off
F4 Fan pause during defrost
Evaporator fans activation for air
recirculation.
The fans activate for a time defined by F7 if they
F6
have not started working for the F6 time. If
activation time coincides with the defrosting
time, end of defrosting is awaited.
Evaporator fans duration for air
F7
recirculation. Fans working time for F6
Sensor presence
If the evaporator sensor is disabled defrosts
are carried out cyclically with period d0:
dE
defrosting ends when an external device
trips and closes the remote defrost contact
or when time d3 expires.
Defrost type, cycle inversion (hot gas) or
d1
with heater elements
dPo Defrost at Power On
dSE Smart defrost
Smart defrost Setpoint (if dSE=1)
The counting of the time between the defrost
dSt is incremented only if the compressor is ON
and the evaporator temperature is less than
dSt.
dFd Display viewing during Defrost
Net address for connection to TeleNET
Ad
supervision system or Modbus
SEr RS-485 communication protocol
Bdr Modbus baudrate
Prt Modbus parity check
Minimum and maximum temperature
Ald
signalling and alarm display delay
Minimum time between shutdown and
C1 subsequent switching on of the
compressor.
CAL Cold room sensor value correction
LIST OF LEVEL 2 VARIABLES (Installer level)
MEANING
ECP 202 EXPERT – Parameters Abstract
Rev. 01-19
VALUES
0 = Fans run continuously
1 = Fans only run when compressor is working
2 = Fans disabled
0 = Fans run during defrost
1 = Fans do not run during defrost
0 – 240 min
0 = (function not activated)
0-240 sec.
0 = evaporator sensor present
1 = no evaporator sensor
0 = heating element
1 = hot gas
2 = heater with temperature control
0 = disabled
1 = defrost at power-on (if possible)
0 = disabled
1 = enabled
-30 ÷ 30 °C
0 = current temperature
1 = temperature at the start of the defrost
2 = "DEF"
0 ÷ 31 (con SEr=0)
1 ÷ 247 (con SEr=1)
0 = TeleNET protocol
1 = Modbus-RTU protocol
0 = 300 baud 3 = 2400 baud
1 = 600 baud 4 = 4800 baud
2 = 1200 baud 5 = 9600 baud
0 = none
1 = even
2 = odd
0 ÷ 240 min
0 ÷ 15 min
-10,0 ÷ +10,0 °C
DEFAULT
1
1
0 min
10 sec
0
0
0
0
1 °C
1
0
0
6 = 14400 baud
7 = 19200 baud 5
8 = 38400 baud
0
120 min
0 min
0,0 °C
