No. Description
1 CPU Fan Connector (CPU_FAN1)
2 Clear CMOS Jumper (CLRMOS1)
3 TPM Header (TPMS1)
4 ATX Power Connector (ATXPWR1)
5 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
6 COM Port Header (COM1)
7 System Panel Header (PANEL1)
8 Chassis Intrusion and Speaker Header (SPK_CI1)
9 USB 2.0 Header (USB_0_1)
10 Chassis Fan Connector (CHA_FAN1)
11 USB 3.0 Header (USB3_0_1)
12 USB 2.0 Header (USB6)
13 SATA3 Connector (SATA3_1)
14 SATA3 Connector (SATA3_2)
15 SATA3 Connector (SATA3_A2)
16 SATA3 Connector (SATA3_A1)
17 Front Panel Audio Header (HD_AUDIO1)
