Beyerdynamic UNITE TH Kurzanleitung Seite 21

Unite TH – Handheld Transmitter
Frequency response
in HD mode:
Close miking . . . . . . . . . . . . . . 40 - 15,000 Hz
Distant miking
(measured at 1 m) . . . . . . . . . 200 - 15,000 Hz
Max. SPL at 1 kHz. . . . . . . . . . . . 120 dB SPL
Bluetooth® . . . . . . . . . . . . . . . . . . . . . V4.2
USB Type C connector . . . . . . . . . compatible to 5 V power
Battery . . . . . . . . . . . . . . . . . . . . . . . . lithium-ion battery,
Battery monitoring . . . . . . . . . . . . Battery status of
Operating time of
battery . . . . . . . . . . . . . . . . . . . . . . . . > 15 hrs., typ.
Dimensions
Length with
microphone capsule. . . . . . 258 mm
Shaft diameter . . . . . . . . . . . 34 mm
Capsule diameter . . . . . . . . 48 mm
Weight (incl. battery). . . . . . . . . . . 225 g
Temperature range
Charging. . . . . . . . . . . . . . . . . . . . . 0 to +35 °C
Operation. . . . . . . . . . . . . . . . . . . . 0 to +40 °C
Storage . . . . . . . . . . . . . . . . . . . . . . -20 to +45 °C
Relative humidity . . . . . . . . . . . . . . 0 to 90%
7. Service
When servicing is required, please contact an authorised
professional or directly:
beyerdynamic Service- and Logistik Center
E-mail: service@beyerdynamic.de
Never open the device yourself, as this will invalidate all
warranty claims.
8. Trademark
The Bluetooth® word mark and logos are registered trademarks
of Bluetooth SIG, Inc. and all use of these trademarks by
beyerdynamic is licensed. Other trademarks and trade names
are the property of the respective owners.
(HFP - Hands-Free-Profile,
A2DP - Audio streaming)
supplies only,
power consumption
max. 500 mA
replaceable by service
staff only
remaining capacity via
OLED display
21
