be stored immediately in the unpaired receivers. The
status indicator on the receiver will flash yellow ra-
pidly while this happens.
6. Set the switch
pairing is finished, so that the charger can only be
used for recharging.
7. Switch on the transmitter and one receiver to check
that they have both been paired successfully.
After a few seconds, the status indicator on the
receiver should light up green and the display should
show the channel name of the transmitter.
8. If you want to clear the stored pairing information,
hold down the "Copy/Reset button
five seconds. The status indicator
permanently green.
6.

Technical specifications

DECT RF frequency range . . . . . 1880 - 1930 MHz,
DECT transmission power . . . . . . up to 250 mW (peak),
DECT operating range . . . . . . . . . up to 300 m outside
Operating mode. . . . . . . . . . . . . . . Broadcast and/or
Encryption . . . . . . . . . . . . . . . . . . . . . AES-256 bit encryption
Display . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED
DECT audio bandwidth
Low quality (SD) . . . . . . . . . . . . . . 50 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . 50 Hz - 14 kHz (-3 dB)
Simultaneously
active microphones . . . . . . . . . . . 1 x handheld transmitter,
Side-tone and
microphone gain . . . . . . . . . . . . . . individually adjustable
Microphone capsule
Transducer type . . . . . . . . . . Condenser
Operating principle . . . . . . . Pressure gradient
Polar pattern . . . . . . . . . . . . . Cardioid
Unite TH – Handheld Transmitter
back to "Charge only" when the
depending on the country
depending on the country
(line of sight);
the actual operating
range depends upon the
RF output settings, the
surroundings, the signal
absorption, signal
reflection and signal
interference
full-duplex on all routes
display with high contrast
max. 2 x via talkback
functionality
(back electret)
for more than
will then remain
