Product Description And Connections - Eneo VKC-1327C/W3 Bedienungsanleitung

① Housing body
② 17 IR LEDs (VKC-1327C-IR/W3
only).
③ Lens hood
④ Window
⑤ Front cover
⑥ Neck

Product description and connections

⑦ Ball housing
⑧ Rear cover screws, 2x (not visible)
⑨ Rear cover
⑩ Neck fastening screws, 3x
⑪ Screws for installation kit, or (b)
mounting screws, 3x
⑫ Mount base
ⓐ Lens hood
ⓑ Focus adjustment knob
ⓒ Zoom adjustment knob
ⓓ Sensor board
ⓔ Infrared LED
ⓕ IR LED board ASS'Y
ⓖ Power board
ⓗ Video subout
ⓘ OSD menu navigation (Joystick)
