Product Description And Connections - Eneo PXD-2080Z03 Schnellinstallationsanleitung

ⓐ Lens
ⓑ Light sensor for IR-LEDs
ⓒ IR-LEDs
ⓓ IP Reset
ⓔ Micro SD Card Slot
ⓕ RTx Status indicator
ⓖ OSD control joy stick
ⓗ Video Sub-output
ⓘ Mount holes (3x) for dome base
ⓘ ⓐ
ⓙ Clear bubble
ⓚ Ring cover fixing screws (3x)
ⓛ Ring cover
ⓜ ⓝ

Product description and connections

ⓑ ⓒ
ⓞ ⓟ
ⓙ
ⓜ Surface mount holes (4x)
ⓝ Dome base fixing screw taps (3x)
ⓞ Pipe hole
ⓟ Pipe spacer
ⓔ
ⓕ
ⓓ
ⓖ
ⓗ
ⓚ ⓛ
