4. Set the camera direction roughly and fasten three ⑩ neck fastening
screws.
5. Apply the power to the camera.
6. Set the ⓒ zoom and ⓑ focus. After setting zoom and focus, secure the
knobs ⓑ and ⓒ.
7. Adjust the setting parameters by using ⓘ OSD Joystick.
8. Remove the power again.
9. Repeat step 1). This step is a preparation for an easy assembling for
step 10.
10. Replace the existing silica-gel bag with new one after setting camera
control parameters.
11. Assemble the ① housing body to the rear cover by tighten two rear ⑧
cover screws. When securing two ⑧ rear cover screws, do not complete
one at a time and another next. Both screws are recommended to be tighte-
ned evenly a little at a time in turn.
12. Trim the camera before the final secure and completely tighten three ⑩
neck fastening screws.

Installation on Ceiling

It is available for the upside down installation on the ceiling by re-arranging
the camera module inside the housing to be turned 180°.
The modification for upside down mounting must be carried out by autho-
rized personnel.

Setup of the Image Sector

1. Pull off the camera housing.
2. Power up the camera and connect a monitor.
