Additional Information - Faber OPTI-MYST Bedienungsanleitung

7. Place the reservoir back on the receptacle while the reservoir's cap is pointing downwards and the fl at side of the
reservoir is pointing outwards.
8. Carefully put the fuel bed back.
9. Put switch 'A' in the ON position ( I ). (See Figure 2)
Cleaning
WARNING: ALWAYS UNPLUG BEFORE CLEANING THE FIRE
We recommend to clean the following parts once per fortnight and - in the case of intensive use of more than 2 hours
per day - once per week, especially in regions with hard water:
water reservoir, receptacle, adapter, air fi lter, reservoir cap and valve.
For general cleaning, use a soft and clean cloth - never use abrasive cleaning agents. Occasionally use the auxiliary
brush of a vacuum cleaner to remove dust and fl uff from the exhaust grill of the fan.
Water reservoir
1. Remove the water reservoir as described above, put it in the kitchen sink and drain the water.
2. Use the supplied brush to brush the inside of the cap. Pay special attention to the rubber ring in the outer groove
and the middle rubber seal.
3. Pour a little bit of dishwashing liquid into the reservoir, put the cap back, shake well and rinse until all traces of the
dishwashing liquid have disappeared.
4. Fill the reservoir only with fi ltered tap water, put the cap back and don't turn it too tightly.
Receptacle
1. Put switch 'A' in the OFF (0) position.
2. Carefully remove the fuel bed and put it carefully on the fl oor (see Figure 3).
3. Remove the water reservoir by lifting it.
4. Disconnect the electrical connection at the right side of the receptacle (see Figure 6).
5. Loosen the right locking lips of the receptacle by turning these 90º. This way the entire receptacle can be removed
(see Figure 6a).
6. Carefully lift the receptacle. Make sure you keep it straight so that you don't spill water. Put the receptacle in the
kitchen sink.
7. Loosen the left locking lips of the receptacle by turning these 90º and remove the adapter (see Figure 4).
8. Remove the transductor and carefully keep the receptacle slanted (as illustrated) so that the liquid runs out the
receptacle (see Figure 8).
9. Pour a little bit of dishwashing liquid into the receptacle and use the supplied brush to clean all surfaces in the
receptacle carefully. Do this also to the transductor including the metal disks located in the upper groove area (see
Figure 9).
10. Rinse the receptacle and transductor well with clean water after cleaning.
11. Clean the surface of the smoke exhaust of the receptacle's cover using the brush and rinse well with water (see
Figure 10).
12. To mount everything, carry out the aforementioned steps in reverse order.
Air fi lter
1. Put switch 'A' in the OFF (0) position (see Figure 2).
2. Carefully remove the fuel bed and put it carefully on the fl oor (see Figure 3).
3. Carefully slide the air fi lter upwards and out of the plastic holder (see Figure 11).
4. Carefully rinse the fi lter with water in the kitchen sink and dry it with a cloth towel before you return the fi lter in its
place.
5. Put the fi lter back and make sure that the black fi lter is at the front side of the fi re.
6. Put the fuel bed back.
7. Put switch 'A' in the ON position ( I ) (see Figure 2).

Additional Information

Recycling
Electrical appliances may not be thrown in the waste bin together with the normal household rubbish at the end
of their lifespan. Please use the available recycle facilities.
Customer service
The product's warranty is valid for one year from the date of purchase. Within this period, we repair or replace this
product without any charge (with the exception of the light bulbs and depending on availability) and on the condition
that the fi re has been installed and used according to the aforementioned instructions. Your rights according to this
warranty are an addition to your legal rights, which are not affected by this warranty.
If you need service or want to purchase spare parts, please contact the shop in which you bought the fi re or call the
service telephone number of the country listed on the warranty. Keep your receipt as proof of purchase.
20
