LED STATUS INDICATORS

LED state
Green continuous
Green flashing
Orange continuous
Orange flashing
Red continuous
Red flashing

FAULT FINDING

Fault
SMS message EN: MAINS FAILURE
SMS message EN: OA x.ykV!
SMS message EN: OA! x.ykV
SMS message EN: ERROR

SPECIFICATIONS

Input voltage DC (V)
Operating temperature (°C)
Input Fence (kV)
Relay contact (V)
Supply Current
Standby Current

EXTERNAL BATTERY

Battery charging is optimized for a 12V 7 AH valve regulated lead acid battery.
Other 12V lead acid batteries can be used.
Avoiding Battery Leakage
Disposing the Battery
64
Gallagher 3E3115 Alarm System User Manual
Indicates
Alarm system set and either powered by the AC adapter or
a fully charged battery.
Alarms are set, but there is no RJ12 connection to the
energizer (i-Series mode only).
Low battery (changes to red if alarm detected).
Battery voltage above 18V.
Alarm detected, in alarm delay or in alarm.
Alarm Entry delay time elapsed for external inputs.
Solution
Check alarm system power supply.
Alarm system in voltage alarm.
One of the external inputs activated.
Energizer pulse is missed by the alarm
system.
Min
10.8
-10
0
-
45mA
33mA
To avoid battery leakage, only used sealed, valve
regulated (VRLA) or GEL type lead acid batteries.
Batteries must be disposed of safely according to
local regulations.
Max
15
50
10
40
125mA
-
