Use a soft dry cloth with not – abrasive and not – solvent detergents. The device's plug must be removed from the wall socket
before proceeding with any cleaning procedures.
Proceed as follows to disinfect the accessories:
1. Turn the upper part of the nebulizer in an anti-clockwise direction;
2. Disconnect the internal pisper at the base of the nebulizer using the fingers;
3. After using the appliance, disassemble the nebulizer and clean all parts in warm water, rinse carefully and remove excess
water using a soft cloth and leave to dry in a clean place.
4. To disinfect the accessories (except the tube) use denatured alcohol or hypochlorite solutions easily obtainable from
chemists. Before using after cleaning, rinse the accessories in warm water until all traces of the disinfectant have been
eliminated, dry and store in a dry and dust free place.
After each treatment clean thoroughly each component of the nebulizer (except air tube) removing medication residual and
possible impurities. Clean all parts in warm water. Rinse thoroughly making sure that all deposits are washed away and let dry.
For each individual patient it's recommended to use the nebulizer for 6 months or for a maximum of 120 treatments.
The nebulizer must be replaced after a long period of inactivity, if it is deformed or broken, or if the nebulizer nozzle is blocked by
dry medicine, dust, ecc.. Only use the original nebulizer supplied by GIMA with the device
Use the "nose piece" accessory only if expressly indicated by your doctor and paying attention NEVER to introduce inside the nose
the nasal bifurcation, but only bring it as close as possible.
In the presence of infection or microbial contamination prone pathologies, we recommend using your personal accessories
and nebulizer (always consult your doctor).
The device is equipped with a filter that removes any impurities from the air that was sucked in by the compressor. The air filter
must be replaced every 25 hours of functioning or when it result particularly worn.
For replacement, lift the filter and replace with a new one. Only use original GIMA filter.
The mask and tube must be replaced as soon as the materials they are made of show signs of deterioration.
DON'T USE THE DEVICE WITHOUT AIR FILTER
CLEANING DEVICE

CLEANING OF ACCESSORIES

DO NOT BOIL OR PUT IN AUTOCLAVE MASK AND AIR TUBE

STANDARD ACCESSORIES

HI-FLO KIT – REF RE 300300
(Nebulizer HI-FLO, Adult Mask, Pediatric Mask, Air Tube and Mouth-piece,
ACCESSORIES
Nosepiece)
15
1- Air Tube
2- Nebulizer Tank
3- Nebulization Nozzle
4- Nebulizer Top
5- Mouthpiece
6- Adult Mask
7- Pediatric Mask
8- Nosepiece
