No. Description
1
ATX 12V Power Connector (ATX12V1)
2
Chassis Fan / Waterpump Fan Connector (CHA_FAN1/W_PUMP)
3
CPU Fan Connector (CPU_FAN1)
4
2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5
ATX Power Connector (ATXPWR1)
6
USB 3.0 Header (USB_6_7)
7
SATA3 Connector (SATA3_1)
8
SATA3 Connector (SATA3_0)
9
SATA3 Connector (SATA3_3)
10
SATA3 Connector (SATA3_2)
11
System Panel Header (PANEL1)
12
USB 2.0 Header (USB_3_4)
13
Clear CMOS Jumper (CLRMOS1)
14
Chassis Intrusion Header (CI1)
15
SATA3 Connector (SATA3_4)
16
SATA3 Connector (SATA3_5)
17
Chassis Speaker Header (SPEAKER1)
18
TPM Header (TPMS1)
19
Front Panel Audio Header (HD_AUDIO1)
2
