Wireless
LAN
Rear Panel
I/O
Storage
Connector
8
• Intel® 802.11ac WiFi Module (Free Bundle)
• Supports IEEE 802.11a/b/g/n/ac
• Supports Dual-Band (2.4/5 GHz)
• Supports high speed wireless connections up to 433Mbps
• Supports Bluetooth 4.0 / 3.0 + High speed class II
• 2 x Antenna Ports
• 1 x PS/2 Mouse/Keyboard Port
• 1 x DVI-D Port
• 2 x HDMI Ports
• 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
• 6 x USB 3.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
• HD Audio Jacks: Line in / Front Speaker / Microphone
• 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
15 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will
be disabled.
• 1 x Ultra M.2 Socket, supports type 2230/2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module
up to Gen3 x4 (32 Gb/s)**
** Supports Intel® OptaneTM Technology
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
• 1 x TPM Header
• 1 x Chassis Intrusion Header
• 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x Chassis Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
