Overall Dimensions

Length / Width (Simulator only): 45 in x 9.84 in (120 cm x 42.5 cm)
Weight (Simulator only): 25 lbs (11.36 kg)
Simulator Power
External power: Input voltage 9VDC, 1.5A
Internal battery: 7.4V, 4.4Ah, Lithium-Ion
Only use approved SimJunior external power supply and batteries.
Air Pressure
Internal air tank: Max 6 psi
External air connection: Max 16 psi
Temperature Limits
Operating temperatures: +4 ºC to 40 ºC (39 ºF to 104 ºF)
Storage temperatures: -15 ºC to 50 ºC (5 ºF to 122 ºF)
Environment - Simulator only
Relative humidity: 20% -90% (non-condensing)
DO NOT use outdoors in wet conditions.
Not tested with salt spray.
RF Communication
Operation range: 10 m (30 ft) max.
Material Chart for Simulator
Clothes: Cotton, Nylon
Skins and airways: PVC
External hard plastics: PVC, ABS
Inner plastics: Silicone, TPU, PVC, Nitrile
ABS, POM, Nylon + GF
Epoxy-Polyurethane
Metal components: Aluminum, Brass, Steel
Minimum Computer Requirements
• Intel i-core generation 3 or newer
• Score over 3000 PassMark - CPU Mark
• 4 GB RAM
• 120GB hard disk space
• 1366x768 or better
• Headset w/microphone
• USB ports – 2
Minimum Software Requirements
• Windows 7 or Windows 8
• 100% DPI

Specifications

Cleaning Fluids
To clean the Simulator use one of the following:
– 60% Isopropanol alcohol
– 70% Ethanol
– Mild solution of liquid soap and water
IV Fluids
Only use distilled or deionized water to simulate IV and IO fluids.
