Adjust Brightness and Flashlight Mode
1. To set task light, position directional switch to neutral.
2. Pull trigger to cycle through brightness options or to turn off light.
3. Position directional switch to Forward or Reverse to save desired brightness setting and begin tool use.
Refer to illustration #2 on page 2.
While in neutral, tool will remain in task light mode for 10 minutes.
Parts and Maintenance
Tool repair and maintenance should only be carried out by an authorized Service Center.
Refer all communications to the nearest Ingersoll Rand office or distributor.
Product Information: Battery
Product Safety Information
Intended Use:
These batteries are used as the power source for Ingersoll Rand Cordless Products.
● Warning! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
● Save all warnings and instructions for future reference.
● Responsibly recycle or dispose of Batteries. Do not puncture or burn Batteries. Improper disposal may endanger the environment or cause
personal injury.
For additional information, refer to Battery Safety Information Manual Form 10567840.
Manuals can be downloaded from ingersollrandproducts.com
Product Specifications
Models Chemistry
BL2010 Lithium Ion
BL2012 Lithium Ion
BL2022 Lithium Ion
Operating Temperatures
Rechargeable batteries give their best performance when they are operated at a normal room temperature of 59°F to 77°F (15°C to 25°C). An exces-
sively hot or cold battery may prevent or interrupt the battery from being charged or discharged.
Parts and Maintenance
Labels are the only User Replaceable Parts.
Models Warning Labels
BL2010 BL20-99-2
BL2012 BL20-99-3, BL2012-99-AP5
BL2022 BL20-99-4
Refer all communications to the nearest Ingersoll Rand Office or Distributor.
Product Information: Battery Charger
Product Safety Information
Important safety instructions - Save these instructions.
To reduce the risk of fire or electric shock, carefully follow these instructions.
Intended Use:
This Battery Charger is designed for charging Ingersoll Rand batteries only.
● Only use Ingersoll Rand charger with Ingersoll Rand IQ
may cause battery to burst when charging. Personal injury or property damage may result.
● Charger is not user serviceable. Repair should only be carried out by an Ingersoll Rand Authorized Service Center. User service may result
in electric shock, fire and/or serious personal injury.
47644658001_ed1
Voltage (V) Capacity (Ah)
20 3.0
20 2.5
20 5.0
Series Li-Ion batteries. Use of other batteries or chargers may create a risk of fire or
V20
NOTICE
WARNING
Weight (lb (kg))
1.52 (0.69)
0.90 (0.41)
1.59 (0.72)
WARNING
DANGER
WARNING
EN
EN-3
