DEHUMIDIFICATION
Humidity is extracted from the air, collected in the water tank and discharged via the condensation wateroutlet. Only air the room if the humidity of the outside air is
below that in the inside room. Set the function to "Dehumidity".
Caution: In the dehumidify mode, separate setting of the ventilator is not provided, since the lowest ventilation level is already preset to ensure efficient dehumidification
of ambient air. Remove the rubber plug of the condensation water outlet and connect the drainage hose to the upper condensation water outlet. This allows water to flow
continuously in order to obtain a larger drainage capacity. In dehumidification mode, do not allow the flow of outside air into dehumidified room.
In dehumidification mode unit works as a dehumidifier with a very high efficiency and can be used to for eg. Drying laundry, flooded rooms, fresh plaster and floors. To
get the best effect dehumidified room should be closed (no flow of moisture from the outside). Both cold and hot air coming from the unit should remain in dehumidified
room. The condensation water should be drained by the upper outlet (No.1 in the figure below) using the drainage hose to the floor drain or outside the room.
Collection of water in a sufficiently large vessel is permitted. It requires constant supervision so that accumulated water is not overflowed.
1
2
CAUTION!
It is essential to protect the unit from working too environments, eg., cement, gypsum, etc .. The ensuing damage to the unit is excluded from warranty
protection.

ADDITIONAL EQUIPMENT

The unit can be equipped with additional accessories and additional external piloting. The list of additional equipment in available on our website: www.uni-lux.eu
Please contact the dealer to get detailed information.

CLEANING AND MAINTENANCE

Please remove the power plug from the socket before cleaning the unit.
COARSE FILTER
The air filters on the side of the unit can be simply removed by pulling the frame sidewards. When cleaning, use a vacuum cleaner with brush or wash the filters under
running, warm water and dry them with a soft cloth!Please clean the coarse filters before initial use, and regularly twice a week when in use or more often depending
on dust concentration.
ERROR MESSAGES
The mobile air conditioner is equipped with a 3-minute compressor-delay system which means the compressor needs 3 minutes to start. This affects the switching on of
the unit (POWER) as well as switching over from one function to the next, e.g. dehumidify to cooling or heating.
17
