NAME OF THE COMPONENTS
1. Operating panel
2. Cool air outlet grid
3. Hot air outlet grid
4. Upper condensation water outlet with rubber plug
5. Inlet
6. Air filter
7. Inlet
8. Air filter
9. Drain pipe with water tank
10. Connection of external control panel /temperature sensor
11. Installation hose bracket

IMPORTANT INSTRUCTIONS

1. Before initiation, check if the operating voltage specified on the type plate complies with the local network voltage.
2. DO NOT BLOCK THE VENTILATION. Make sure that the air outlet and air inlet are never blocked.
3. Only operate the unit on a horizontal surface to ensure no water leaks out.
4. The unit must not be operated in an area with explosive and caustic substances.
5. Clean the air filter regularly. A contaminated air filter reduces capacity.
6. Please wait at least 5 minutes after switching off the unit before switching it back on, to ensure the compressor is not damaged.
7. The compressor of the unit has a power demand of at least 7 amps. Do not use any extension cable with this unit.
8. The unit is designed for the cooling, heating and dehumidification of inside rooms. Other use is excluded or conditionally acceptable.
9. If the power cable is damaged, it must be replaced by a qualified specialist for safety reasons.
10.CAUTION! This unit may only be used by persons (including children) with reduced physical, sensorial or mental capacity or with insufficient experience and lack of
specialist know-how, if such persons are supervised by a person responsible for their safety or who has been trained in the use of the unit. Children should be supervised
to ensure they do not play with the unit.

DESCRIPTION OF FUNCTIONS:

CAUTION!
Depending on the version of the device, the distribution of
lights and control buttons may be different from the figure.
5
2
7
1
1
2
1. [POWER]
Press this switch to switch on or off.
2. [FUN]
Press this switch to select between the functions "Cooling", „Heating" or „Dehumidity".
3. [TEMP+]
Press this switch in the cooling function in order to set the required room temperature by 1°C respec-
tively up to a maximum temperature of 30°C.
Press this switch in the heating function in order to set the required room temperature by 1°C respec-
tively up to a maximum temperature of 25°C.
4. [TEMP-]
Press this switch in the cooling function in order to set the required room temperature by 1°C respec-
tively up to a minimum temperature of 17°C.
Press this switch in the heating function in order to set the required room temperature by 1°C respec-
tively up to a minimum temperature of 15°C
3
6
CAUTION: To change the reading from Celsius „°C" to Fahrenheit „°F" degrees and viceversa, press
[FUN] key for 5 seconds. (option)
8
4
13
11
3
5/6
4
7/8
9
10
