Extremis Sol+Luna Borealis Handbuch Seite 16

English
ASSEMBLY
A
Borealis
1. Lay the frame with the batyline fabric on trestles.
2. Place the 4 caps on the ends and fasten them with
4 pre-coated M6x12 bolts.
3. Now attach the two feet to the frame with 4 pre-
coated M6x12 bolts each.
4. Sol+Luna has 5 positions.
B
Rugleuning
1. Before you attach the backrest, you can opt to
add certain accessories such as the locker and
storage net.
2. Attach the left and right back supports to the
backrest with 2 pre-coated M8x50 bolts each.
Please note: Take care to ensure the back
supports are on the right side.
3. Now insert the backrest into the holes at either
end end of the lounger.
C
Mattress
1. Position the mattress on the lounger and attach
it to the batyline with the loops on the underside
of the mattress. Note that the loop closest to the
middle needs needs to be at the head end.
D
Bolster pillow + counterweight
1. Start by putting the bolster pillow through one
loop of the weight.
2. Now put it through the second loop, ensuring that
it is centrally positioned.
3. Now lay the whole thing over the headrest as
shown in the diagram. You can adjust the height
by hanging the weight higher of lower.
E
Locker
1. Slide the upper edge of the keder into the highest
groove of the backrest as shown in the diagram.
2. Now position the backrest between the two leg
supports and attach it with 2 pre-coated M8x30
bolts on either side. You will find a small lock in
the locker: see the instructions on the packaging.
16
F
Storage net
1. Slide the upper edge of the keder into the middle
groove of the backrest as shown in the diagram.
Please note: Make sure the pouch is on the same
side as the lounger.
2. Position the storage net in the middle of the
lounger and then slide the fibreglass rod provided
into the lowest loop.
3. Now position the backrest between the two leg
supports and attach it with 2 pre-coated M8x30
bolts on either side.
4. Next attach the storage net to the underside of the
frame, by pushing the fibreglass rod through the
hole on one side first before you push it through
the hole on the other side. Then put a cap on both
ends.
G
Tapa table
1. Attach the tabletop to the table support with 3
pre-coated M6x12 bolts.
2. Now insert it into one of the four holes in the
lounger.
H
Linking table
1. Attacht the tabletop to the 2 table supports with 3
pre-coated M6x12 bolts on each side.
2. Now insert it into one of the four holes in the
lounger.
MAINTENANCE
Batyline fabric
Clean with lukewarm water and a gentle detergent.
Tips for stubborn stains or mould:
1. Clean with water and "Cleaner 500":
en.sergeferrari.com/corporate-en/cleaner-500
2. Spray "Cleaner 500" onto the batyline and allow it
to soak in for 2-3 minutes.
3. Rub the surface repeatedly with a soft brush using
a circular motion.
4. Then rinse with plenty of water to prevent any
remaining dirt from drying into the fabric.
5. Finally, wipe carefully with a dry cloth.
Never use abrasive substances or solvents!
Powder-coated parts
Clean with lukewarm water and a gentle detergent.
