The video transmitter installed in the BNF FPV version includes an
integrated On Screen Display system (OSD). The OSD delivers the
pilot useful information on the video display. The OSD shows the Flight
Mode, time aloft, and voltage. A call sign is also available on the OSD to
display your HAM call sign to satisfy amateur radio rules.
The video transmitter frequency and power output can be set directly
from compatible Spektrum transmitters or set in the OSD menu.
OSD Menu
The OSD has a menu system which has options where the pilot can
make changes.
1. To enter the menu the motor must be disarmed.
2. Flip the flight mode switch back and forth twice to enter the menu.
3. To navigate the menu use elevator stick to move up and down through
the menu, and aileron stick to move side to side through the menu.
Available Frequencies, North America (mHz)
Band CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
Band A 5865 5845 5825 5805 5785 5765 5745 5745
Band B 5733 5752 5771 5790 5809 5828 5847 5866
Band E 5705 5685 5665 5665 5885 5905 5905 5905
FS/IRC 5740 5760 5780 5800 5820 5840 5860 5860
RaceBand 5732 5732 5732 5769 5806 5843 5843 5843
