REMOTE CONTROL
DISPLAY
1
2
3
4
5
6
7
1
2
3
4
5
6
7
8
9
10
1 MODE Symbols
2 FAN SPEED Symbols
8
3 PLASMACLUSTER Symbol
9
4 AIR FLOW Symbol (COOL/DRY/AUTO)
10
5 AIR FLOW Symbol (HEAT)
11
6 COANDA AIR FLOW Symbol (HEAT)
12
7 BATTERY Symbol
8 SILENT Symbol
9 TRANSMITTING Symbol
13
10 SELF CLEAN Symbol
11 COANDA AIR FLOW Symbol (COOL/DRY)
14
12 FULL POWER Symbol
13 SPOT AIR Symbol
14 TEMPERATURE Indicator
15
15 TIMER OFF Indicator
16 TIMER ON Indicator/CLOCK
16
GB-3
1 TRANSMITTER
2 COOL Button
3 HEAT Button
4 STOP Button
5 PLASMACLUSTER Button
6 AUTO Button
7 DRY Button
8 TEMPERATURE Button
9 1.2.3.5h OFF TIMER Button
10 FAN Button
11 SWING Button(vertical direction)
12 SWING Button(horizontal direction)
13 SPOT AIR Button
14 SILENT Button
11
15 FULL POWER Button
12
13
16 COANDA AIR FLOW Button
17 SELF CLEAN Button
14
15
18 TIMER SET/CANCEL Button
16
19 TIME ADVANCE Button
17
20 TIME REVERSE Button
18
19
21 CLOCK Button
20
22 DISPLAY Button
21
22
23 TIMER ON Button
23
24 TIMER OFF Button
24
25
25 RESET Button
