Using the TDS2MEM Storage Memory and Communications Module
Saving Oscilloscope Settings
You use the Save Setup menu (SAVE/RECALL
Setup) to save the current oscilloscope settings to file name
TEKnnnn.SET in the specified folder or in nonvolatile setup memory.
A setting file contains an ASCII text string that lists the oscilloscope
settings.
Options
Save To
Setup
Select Folder
Save
8
Settings or
Submenus Comments
Setup Specifies saving the current oscilloscope
settings to nonvolatile setup memory
File Specifies to save the current
oscilloscope settings to a file on the CF
card.
1 to 10 Specifies the nonvolatile setup memory
location.
Lists the contents of the current CF card
folder and displays the following menu
items.
Change Folder See Managing Files and Folders on
page 14.
New Folder Returns to the Save All menu.
Saves the settings to the specified setup
memory location.
filename Saves the settings to the automatically
generated file name in the current CF
card folder.
Action = Save
TDS2MEM User Manual
