Using the TDS2MEM Storage Memory and Communications Module
Saving Information Using the PRINT Button
You use the Save All menu (SAVE/RECALL Action = Save All) to
set the PRINT button to do one of three functions:
Automatically save oscilloscope information to multiple files in a
folder.
Save the screen image to a file.
Print the screen image to the current printer port.
Options
Print Button
Select Folder
About
Save All
TDS2MEM User Manual
Settings or
Submenus Comments
Saves All To Sets the print button to save all active
Files oscilloscope information (waveforms,
screen image, settings) to files in a new
subfolder in the current CF card folder.
See Saves All to Files on page 6.
Saves Image To Sets the print button to send the screen
FIle image to a file on the CF card.
Prints Sets the print button to send the screen
image to the current printer port.
Lists the contents of the current CF card
folder and displays the following menu
items.
Change Folder See Managing Files and Folders on
page 14.
New Folder
Back Returns to the Save All menu.
Displays the help text for this task.
5
