Using the TDS2MEM Storage Memory and Communications Module
Saving a Screen Image to a File
You use the Save Image menu (SAVE/RECALL
Image) to save the oscilloscope screen image to a default file named
TEKnnnn.???, where .??? is the specified graphics file format. You
can import screen image files into many spreadsheet and word
processing applications.
Options
File Format
About Saving
Images
Select Folder
Save
TDS2MEM User Manual
Settings or
Submenus Comments
BMP, PCX, Sets the screen image graphics file
TIFF, RLE, format.
EPSIMAGE
Displays the help text for this task.
Lists the contents of the current CF card
folder and displays the following menu
items.
Change Folder See Managing Files and Folders on
page 14.
Layout Select portrait or landscape image
layout.
Ink Saver Toggles Ink Saver mode On or Off (color
On, Off models only).
New Folder See Managing Files and Folders on
page 14.
filename Saves the screen image to the
automatically generated file name in the
current CF card folder.
Action = Save
