1.3 Motherboard Layout

PS/2
MOUSE
PS/2
KEYBOARD
SERIAL
PORT
(COM1)
26
LAN
USB 2.0
PORTS
USB 2.0
PORTS
25
LINE OUT
Line
LINE IN
In
Mic
MIC IN
In
24
JR1
23
JL1
22
AUDIO
CODEC
SUPER
21
20
1 PS2_USB_PWR1 Jumper
2 CPU Fan Connector (CPU_FAN1)
3 CPU Socket
4 North Bridge Controller
5 184-pin DDR DIMM Slots (DDR1- 2)
6 ATX Power Connector (ATXPWR1)
7 Secondary IDE Connector (IDE2, Black)
8 Primary IDE Connector (IDE1, Blue)
9 AGP Slot (1.5V_AGP1)
10 FSB Select Jumpers
(FSB_SEL0, FSB_SEL1, FSB_SEL2)
11 South Bridge Controller
12 Chassis Fan Connector (CHA_FAN1)
13 Floppy Connector (FLOPPY1)
1 2
17.8cm (7.0 in)
PS2_USB_PWR1
1
CPU_FAN1
J1
VIA
KT400A
CHIPSET
AUX1
CD1
K7VT4A+
AGP 8X
AUDIO1
LAN
PHY
PCI1
DDR400
PCI2
I/O
PCI3
2MB
BIOS
PCI4
CMOS
BATTERY
PCI5
CLRCMOS2
1
1
IR1
19 18
3 4 5 6
IDE1
1.5V_AGP1
1 FSB_SEL0
1 FSB_SEL1
1 FSB_SEL2
VIA
USB2.0
5.1CH
VT8235
ATA133
FSB333
FLOPPY1
PWR_LED1
1
PLED PWRBTN
1 1 1
USB45 HDLED RST
SPEAKER1
17 16
14 Power LED Connector (PWR_LED1)
15 System Panel Connector (PANEL1)
16 Chassis Speaker Connector (SPEAKER 1)
17 USB 2.0 Connector (USB45, Blue)
18 Infrared Module Connector (IR1)
19 Clear CMOS Jumper (CLRCMOS2)
20 Flash Memory
21 PCI Slots (PCI1- 5)
22 Front Panel Audio Connector (AUDIO1)
23 JR1 / JL1 Jumpers
24 Internal Audio Connector: CD1 (Black)
25 Internal Audio Connector: AUX1 (White)
26 J1 Jumper (FID0, FID1, FID2, FID3, FID4)
7
IDE2
7
8
9
10
11
12
CHA_FAN1
13
14
PANEL 1
15
