1.2

Specifications

Platform:
CPU:
Chipsets:
Memory:
IDE:
Floppy Port:
Audio:
LAN:
Hardware Monitor: CPU temperature sensing
PCI slots:
AGP slot:
USB 2.0:
TM
ASRock I/O :
BIOS:
OS:
ATX Form Factor: 12.0-in x 7.0-in, 30.5 cm x 17.8 cm
Supports Socket A (462 pins) for
TM
AMD Athlon / Athlon
North Bridge: VIA KT400A, FSB@333 MHz
South Bridge: VIA VT8235CD, supports USB 2.0, ATA 133
2 DDR DIMM Slots: DDR1 and DDR2
PC3200 (DDR400) for 1 DDR DIMM slot, Max. 1GB
PC2100 (DDR266) / PC2700 (DDR333) for 2 DDR DIMM slots,
Max. 2GB
IDE1: ATA 133 / Ultra DMA Mode 6
IDE2: ATA 133 / Ultra DMA Mode 6
Supports up to 4 IDE devices
Supports up to 2 floppy disk drives
5.1 channels AC'97 Audio
Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Motherboard temperature sensing
CPU overheat shutdown to protect CPU life
(ASRock U-COP)(see CAUTION 1)
CPU fan tachometer
Chassis fan tachometer
Voltage monitoring: +12V, +5V, +3.3V, Vcore
5 slots with PCI Specification 2.2
1 AGP slot, supports 1.5V, 8X/4X AGP card (see CAUTION 2)
6 USB 2.0 ports:
includes 4 default USB 2.0 ports on the rear panel,
plus one header to support 2 additional USB 2.0 ports
(see CAUTION 3)
1 PS/2 keyboard port, 1 PS/2 mouse port,
1 serial port: COM1, 1 parallel port: ECP/EPP support,
1 RJ-45 port,
4 default USB 2.0 ports,
Audio Jack: Line Out / Line In / Microphone + Game port
AMI legal BIOS, Supports "Plug and Play",
ACPI 1.1 compliance wake up events,
SMBIOS 2.3.1 support,
CPU frequency stepless control
(only for advanced users' reference, see CAUTION 4)
Microsoft ® Windows
TM TM
XP / Duron processor
® 98 SE / ME / 2000 / XP compliant
5
