Close and block
Block
Release
Timed Courtesy light
Courtesy light: on/off
Apartment block
8 – Robus 600-1000
Closing
program the required operating mode,
selecting in Table 1-D ("command config-
uration" > "closing" > operating mo de...)
Step step
program the required operating mode, ss
apartment block 1 ("command config-
uration" > "step step" > operating mo -
de: ss apartment block 1)
When this command is sent the control unit
activates the application to complete the Clos-
ing manoeuvre until the position is reached as
set in the function "closing"(Control unit func-
tions > installation > positions > closing) and
the automation is then blocked.
Input configured as normally open.
When this command is sent, the control unit is
blocked and does not perform any type of
command, with the exception of "High priority
step-step", "Release", "Release and close" and
"Release and open".
Input configured as normally open.
When this command is sent, the control unit is
released restoring normal operating status (all
commands sent can be performed)
Input configured as normally open.
This command enables activation of the cour-
tesy light on the control unit and that program-
mable on Output 1 and Output 2.
The courtesy light remains active for the time
as programmed in the function "courtesy light
ti me" (Control unit functions > advanced pa -
rame ters > output configuration > courtesy li -
ght ti me).
For the courtesy light connected to Output 1,
the command is only enabled when this output
is programmed in "courtesy light" mode (Con-
trol unit functions > advanced parameters >
out put configuration > output 1 (flash) > cour-
tesy light).
Note – When the courtesy light is already
active and the command "timed courtesy light"
is sent again, the time programmed in the func-
tion "courtesy light time" is reloaded.
Input configured as normally open.
This command enables activation and deactiva-
tion of the courtesy light on the control unit and
that programmable on Output 1 and Output 2.
For the courtesy light connected to Output 1,
the command is only enabled when this output
is programmed in "courtesy light" mode (Con-
trol unit functions > advanced parameters >
output configuration > output 1 (flash) > cour-
tesy light).
CAUTION! – The courtesy light is switched off
automatically if the relative time interval elaps-
es, as programmed in the function "courtesy
light time" (Control unit functions > advanced
parameters > output configuration > courtesy
light time).
Input configured as normally open.
This command is factory set to Input 1,
with operating mode "ss apartment block
1" and operating sequence "open- stop -
close - open".
When this command is sent, the control unit
activates the application to complete the next
manoeuvre following the previous one (or still in
progress) according to the sequence of ma -
noeuvres as envisaged in the programmed
sequence.
Note – This apartment block step step com-
mand is used for apartment blocks and in gen-
eral envisages programming of all apartment
block transmitters with a single "apartment
block step step" key.
Input configured as normally open.
