radio channel no.2
radio channel no.3
radio channel no.4
output 2
In this output the user can select one of the functions specified in Table 3.
FUNCTION
sca (= gate open indicator)
gate open
gate closed
maintenance indicator light
flashing light
16 – Robus 600-1000
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is set with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit
receiver, as previously memorised with a command, the con-
trol unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is set with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit
receiver, as previously memorised with a command, the con-
trol unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is set with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit
receiver, as previously memorised with a command, the con-
trol unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
TABLE 3: OUTPUT CONFIGURATION
DESCRIPTION
The programmed light indicates the operating status of the
control unit.
light off = application in maximum Closing position;
slow flashing = application Opening manoeuvre execution
phase;
quick flashing = application Closing manoeuvre execution
phase;
light permanently on = application in maximum Opening
position.
The programmed light indicates the operating status of the
control unit.
light on = application in maximum Opening position;
light off = application in other positions.
The programmed light indicates the operating status of the
control unit.
light on = application in maximum Closing position;
light off = application in other positions
The programmed light indicates the count of manoeuvres
completed and therefore the need (or not) for system mainte-
nance operations.
light on for 2 sec at start of Opening manoeuvre = number
of manoeuvres less than 80%;
light flashing during execution of entire manoeuvre = num-
ber of manoeuvres between 80 and 100%;
light always flashing = number of manoeuvres over 100%.
This function enables the flashing light to indicate execution of
a manoeuvre in progress with flashes at regular intervals (o.5
sec ON, 0.5 sec OFF).
