Troubleshooting

Make sure that your monitor is properly installed if you have encountered any trouble using this product.
•
There is no picture on the screen.
Check: Power saving mode. Press any key and move the mouse to deactivate the mode
Signal cable connector pins. If there are bent or missing pins, contact your place of purchase.
•
Characters look too dark or too light
Check: Using OSD Menu to adjust the Brightness.
•
When your monitor needs to be adjusted?
Check: If the resolution of frequency is being changed.
•
The text appears on the screen are unclear.
Check: Make sure the resolution or refresh rate match with the Display Mode.
•
Touch panel function does not respond.
Check: Make sure that touch screen controller driver must be installed into your PC system and calibrate
touch screen before you use it.

Supported Timing

Item
Standards
1
VGA
2
VESA
3 VESA
4
VESA
5
SVGA
6
VESA
7
VESA
8
VGA
9
XGA
10
VESA
11
VESA
12
VESA
13
VESA
A = Analog Mode; D = Digital Mode, G = Sync On Green Mode
If the input timing is closed to one of the above, generally it can be displayed well by optimum adjusting.
