3. Parts Name and Functions

(5) IR LED (Infrared LED)
1

Built-in lens

2 Top cover
3 Focus handle
4 Zoom handle
5 IR LED (Infrarot-LED)
() Top cover
(4) Zoom handle
() Focus handle
() Built-in lens
Built-in varifocal lens camera
Used to access focus or zoom handle. After access, be sure to close it.
Used to provide for accurate focussing of object within the lens field of view.
Used to adjust zoom magnification by turning.
Only Day & Night Series
