Figure 1. SuperTrak EX4650 card
Figure 2. SuperTrak EX4650A card
I2C/SMBus connector
UART connector
UART connector
CPU Fan connector
I2C/SMBus connector
SAS Port
Ch1-4
Activity and Fault LED Pins
Step 2: Installing the SuperTrak Card
Activity and
Fault LED Pins
BBU module
connector
CPU Fan connector
5
Global and
Aggregate
LED Pins
SAS Ports
Ch1-4
BBU module
connector
Aggregate
LED Pins
Global
LED Pins
