7 Cutting Pylon to Length
7
Deburr end of pylon.
9
Loctite (243) & tighten (25 Nm) top housing bolts.
Attach and align socket.
8 Foot Shell Removal & Pylon/Spring Replacement
Be aware of finger trap hazard at all times.
1
4
Remove top
housing from
pylon.
(continued)
8
Slide pyramid into top housing (or fit preferred
alignment option).
4
25 Nm
2
7
4
Remove
lower carrier
bolt.
938306S/2-0818
