2 Construction
Principal parts:
• Carrier (aluminum)
• Heel & Toe Springs (e-carbon)
• Spring attachment screws (titanium)
• Glide Sock (UHM PE)
• Foot shell (PU)
Toe Spring
Screw
(Loctite 243)
4
25 Nm
13A/F
Heel Spring
Heel Spring
Screws
(Loctite 243)
4
15 Nm
3
Carrier
Toe/Pylon
Glide
Sock
Foot
Shell
