MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
Module MR2 - MR4
FEEDBACK-ANSCHLUSS AKTIV
PFHd SFF MTTFd
3,09E-10 99,6% 2335,94
8,53E-11 99,7% 24453,47
6,63E-11 99,8% 126678,49
8,23E-09 99,5% 70,99
7,42E-10 99,5% 848,16
1,07E-10 99,7% 12653,85
3,32E-09 99,5% 177,38
3,36E-10 99,6% 2105,14
8,19E-11 99,7% 28549,13
tcycle1: 300s (1 Schaltausgang alle 5 Minuten)
tcycle2: 3600s (1 Schaltausgang stündlich)
tcycle3: 1 Schaltausgang täglich

8540780 • 05/11/2018 • Rev.34x
MR2 – MR4: TECHNISCHE DATEN ZUR SICHERHEIT
DCavg
98,9% tcycle1
97,7% tcycle2 DC13 (2A)
92,5% tcycle3
99,0% tcycle1
99,0% tcycle2 AC15 (3A)
98,4% tcycle3
99,0% tcycle1
98,9% tcycle2 AC15 (1A)
97,5% tcycle3

FEEDBACK-ANSCHLUSS NICHT AKTIV
PFHd SFF MTTFd
9,46E-10 60% 2335,93
1,08E-10 87% 24453,47
6,75E-11 97% 126678,5
4,60E-07 50% 70,99
4,49E-09 54% 848,15
1,61E-10 79% 12653,85
7,75E-08 51% 177,37
1,09E-09 60% 2105,14
1,00E-10 88% 28549,13
DCavg
0 tcycle1
0 tcycle2 DC13 (2A)
0 tcycle3
0 tcycle1
0 tcycle2 AC15 (3A)
0 tcycle3
0 tcycle1
0 tcycle2 AC15 (1A)
0 tcycle3
